OEM PRODUCT FAMILY / 06
Mining W-Straps
Roll-formed steel straps manufactured for buyer-defined roof and rib support configurations. Final dimensions and acceptance criteria are confirmed against the buyer-approved order specification.
MANUFACTURING OVERVIEW
Mining W-Straps
Mining W-Straps are manufactured to buyer-approved profile drawings, dimensions, hole or slot layouts, material, coating and interface requirements. International inquiries should provide those manufacturing inputs before quotation.
Build to specificationOrder-specific inspectionExport packing
Reference Specification
- Typical Sizes
- APAC 280/290 mm; EME SP270/SP320; 0.9-7 m
- Common Configurations
- Roll-formed roof straps manufactured for buyer-defined bolt, mesh and plate configurations
- Customizable Parameters
- Working/overall width; profile drawing; thickness; length; hole/slot; centers; end distance; coating
- Performance Fields
- Buyer-specified section load/bending and material requirements; dimensional inspection scope confirmed in the order
- Quotation Requirements
- Upload your strap profile and hole layout for a manufacturability review.
Reference values support enquiry planning. The quotation and purchase order control final dimensions, material, performance, inspection and packing.
Start OEM RFQ ↗COMMON CONFIGURATIONS
- APAC 280/290 mm strap family
- EME SP270/SP320 profile options
- 0.9-7 m common length range
- Round hole, slot and custom center layouts
- Profile drawing reviewed before production
OEM VARIABLES TO CONFIRM
- Working/overall width
- profile drawing
- thickness
- length
- hole/slot
- centers
- end distance
- coating
OEM MANUFACTURING REVIEW
What turns a product enquiry into a controlled order.
Xianhong confirms manufacturability and production scope. The buyer and project engineer remain responsible for product selection, support design, installation and site suitability.
Verification
Inspection points, sampling, required reports, certificate scope and any third-party review.
Supply Model
Neutral packing, buyer label, private label, bundle limits, marks and export documentation.
Order Control
Final quotation and purchase-order documents control the manufactured and inspected product.
TECHNICAL INPUTS
Prepare a quote-ready specification.
