OEM PRODUCT FAMILY / 07
Mining Bearing Plates
Dome, flat and formed plates manufactured for buyer-specified resin-bolt, friction-bolt or cable-bolt interfaces. Final dimensions and acceptance criteria are confirmed against the buyer-approved order specification.
MANUFACTURING OVERVIEW
Mining Bearing Plates
Mining bearing plates are manufactured against buyer-approved bolt, seating and component-interface requirements. Size alone is not enough for quotation: the approved interface reference, hole or neck geometry, buyer-specified plate-load requirement and surface treatment should be provided.
Build to specificationOrder-specific inspectionExport packing
Reference Specification
- Typical Sizes
- 150x150; 200x200; 300x300; 4-12 mm
- Common Configurations
- Dome, flat and formed plates manufactured for buyer-specified resin-bolt, friction-bolt or cable-bolt interfaces
- Customizable Parameters
- Plate W x L x T; hole/neck; dome height; seat geometry; steel; coating; buyer-approved bolt/interface reference
- Performance Fields
- Buyer-specified load / deflection requirements — inspection or test scope to be confirmed in the quotation and approved order documents.
- Quotation Requirements
- Provide the buyer-approved bolt/interface reference and any buyer-specified plate-load requirement; inspection or test scope is confirmed in the quotation and order documents.
Reference values support enquiry planning. The quotation and purchase order control final dimensions, material, performance, inspection and packing.
Start OEM RFQ ↗COMMON CONFIGURATIONS
- Dome plates for friction bolt systems
- Flat plates for rebar and resin bolts
- Cable bolt plates for barrel and wedge systems
- 150, 200 and 300 mm common square formats
- Buyer-specified load / deflection requirements — inspection or test scope to be confirmed in the quotation and approved order documents.
OEM VARIABLES TO CONFIRM
- Plate W x L x T
- hole/neck
- dome height
- seat geometry
- steel
- coating
- buyer-approved bolt/interface reference
OEM MANUFACTURING REVIEW
What turns a product enquiry into a controlled order.
Xianhong confirms manufacturability and production scope. The buyer and project engineer remain responsible for product selection, support design, installation and site suitability.
Verification
Inspection points, sampling, required reports, certificate scope and any third-party review.
Supply Model
Neutral packing, buyer label, private label, bundle limits, marks and export documentation.
Order Control
Final quotation and purchase-order documents control the manufactured and inspected product.
TECHNICAL INPUTS
Prepare a quote-ready specification.
