OEM PRODUCT FAMILY / 05
Welded Mine Mesh
Flush-cut welded steel mesh for underground roof, rib and shotcrete reinforcement. Final dimensions and acceptance criteria are confirmed against the buyer-approved order specification.
MANUFACTURING OVERVIEW
Welded Mine Mesh
Welded mine mesh is manufactured for buyer-defined roof, rib and shotcrete reinforcement configurations. The buyer-approved drawing or specification must define whether each grid value is a clear opening or centre-to-centre spacing, together with the wire, panel and acceptance requirements.
Build to specificationOrder-specific inspectionExport packing
Reference Specification
- Typical Sizes
- 5.6/100x100; 4/75x75; 4/100x100 grid references; measurement convention per buyer-approved specification; width up to 2.4 m
- Common Configurations
- Flush-cut welded panels for roof, rib and shotcrete reinforcement
- Customizable Parameters
- Wire diameter/profile; clear opening or wire-pitch convention; panel W x L; edge; material/mechanical requirement; weld requirement; coating requirement; packing requirement
- Performance Fields
- Buyer-specified wire/material, weld, coating and dimensional acceptance requirements
- Quotation Requirements
- Send the approved mesh drawing or specification, panel dimensions, wire/grid definition, edge requirements, quantities and any buyer-approved overlap or interface requirements rele
Reference values support enquiry planning. The quotation and purchase order control final dimensions, material, performance, inspection and packing.
Start OEM RFQ ↗COMMON CONFIGURATIONS
- 5.6 mm wire with 100 x 100 mm grid reference; measurement convention per buyer-approved specification
- 4 mm wire with 75 x 75 or 100 x 100 mm grid reference; measurement convention per buyer-approved specification
- Panel width options up to 2.4 m
- Bright, galvanized or heavy galvanized finish by order
- Wire tensile and weld shear fields for inspection
OEM VARIABLES TO CONFIRM
- Wire diameter/profile
- clear opening or wire-pitch convention
- panel W x L
- edge
- material/mechanical requirement
- weld requirement
- coating requirement
- packing requirement
OEM MANUFACTURING REVIEW
What turns a product enquiry into a controlled order.
Xianhong confirms manufacturability and production scope. The buyer and project engineer remain responsible for product selection, support design, installation and site suitability.
Verification
Inspection points, sampling, required reports, certificate scope and any third-party review.
Supply Model
Neutral packing, buyer label, private label, bundle limits, marks and export documentation.
Order Control
Final quotation and purchase-order documents control the manufactured and inspected product.
